MINI DS211 LED Display Professional Digital Oscilloscope Inspection And Maintenance Electronic Equipment ,Professional Designed

<p>Describe: </p><p>This product is suitable for: </p><p>1. On-site inspection and maintenance of common electronic equipment (inverter air conditioner or industrial variable frequency power supply, AC / DC switching power supply or inverter, elevator and building fire protection equipment, industrial field control circuit) </p><p>2. Hardware maintenance or software debugging RS232, RS485, I2C, CAN and other communication interface circuits, LED display and keyboard scanning drive circuit, brushless motor drive circuit </p><p>3. equipment and circuits, electronic toys and remote control models, overhaul of automotive electronic circuits </p><p>4. School teaching practice and the development of student electronic production </p><p>5. Applications that require slow signal changes (eg relay and switch contact jitter, battery charge and discharge curves, regulated power supply load transient response, temperature sensor characteristic measurements) </p><p>6. Power supply related electronic circuits (silicon voltage regulation, power factor compensation, electronic energy saving lamps, sodium lamps, xenon lamps,lamps, etc.). For other applications, such as CPU clocks, access, bus and USB or Ethernet signal measurements, high frequency and video circuits, and signal analysis that requires FFT, oscilloscopes do not have this feature. It is especially worth mentioning that this pocket oscilloscope can be powered by the built-in battery, so when the field is measured, the ground wire is completely suspended, which may be exactly the same as the multimeter, no matter which one, there is no need to consider the problem of grounding isolation.</p><p></p><p>Parameter:</p><p>Number of channels 1 analog channel + 1 internal channel</p><p>Input impedance 1M</p><p>Coupling mode DC / AC</p><p>Trigger mode rising/falling edge trigger</p><p>Automatic adjustment mode AUTO_FIT</p><p>Operating waveform -A, RecA, A + RecA</p><p>Signal output square wave, sine wave, triangle wave, sawtooth wave</p><p>Trigger mode auto, normal, single, none, scan</p><p>Measured signal frequency/cycle/duty cycle,</p><p>Voltage peak-to-peak/effective value/maximum/minimum/average</p><p>Store 8MB internal USB flash drive</p><p>The number of APP can be loaded 1</p><p>Operation button</p><p>USB interface MicroUSB</p><p>Battery 550mAh</p><p>Screen size 2.8 inches</p><p>Screen resolution 320×240</p><p>Size 106.5mmX55.7mmX11.5mm</p><p>Weight 65g</p><p>Open source situation application layer open source</p><p></p><p>Package includes :</p><p>Package 1</p><p>1 * DS0211 Digital Oscilloscope </p><p>1 * 10:1 Probe</p><p>1 * USB Cable</p><p>Package 2</p><p>1 * 10:1 Probe</p><p>Package 3</p><p>1 * 100:1 Probe</p><p>Package 4</p><p>Tool bag*1</p><p></p><p>ds211 mini oscilloscope,electronic equipment,digital oscilloscope,led display</p><p>Related Products: </p><p>oscilloscope, </p><p>portable oscilloscope, </p><p>automotive oscilloscope, </p><p>oscilloscope automotive, </p><p>lab oscilloscopes, </p><p>osciloscopio, </p><p>osciloscopio automotriz, </p><p>handheld oscilloscope, </p><p>digital oscilloscope, </p><p>usb oscilloscope</p>

• Analog bandwidth 200KHz
• Maximum sampling rate 1MSa / s
• Maximum storage depth 8K
• Horizontal scanning speed 1uS / Div~2S / Div (1-2-5 steps)
• Vertical sensitivity 20mv / Div~10V / Div (1-2-5 steps)
